PCB Design & Layout
Mastering the architecture of hardware. From simple breakouts to 32-layer HDI assemblies, we engineer the physical foundations of your technical vision.
Precision Engineering Flow
Our PCB design process is meticulously structured to prevent costly respins. We focus intensely on signal integrity, power distribution, and thermal management. We utilize advanced EDA tools like Altium and Cadence to create production-ready layouts.
Whether you need a compact wearable device requiring micro-vias and blind/buried technology, or a high-power industrial control board with heavy copper, our engineers adapt the stack-up precisely to your needs.
Service Capabilities
High-Speed Digital
Impedance-controlled routing, length matching, and differential pair optimization.
RF & Microwave
Custom antenna design, matching networks, and cross-talk mitigation.
Rigid & Rigid-Flex
Space-constrained multi-board layouts for wearables and medical devices.
DFM & DFA Ready
Manufacturing-ready Gerber/OBD++ files with precise drill and pick-and-place data.
Start Your Design
Upload your schematics today and get a technical design review from our senior hardware engineers.
Request ConsultationLayer Count
Up to 32 Layers
Materials
FR4, High-Tg, Rogers
Inspection
AOI & Flying Probe
